Water tightness
550 Pa
L6 · Xining
Heavy-Duty Sliding Door
A robust sliding platform for broad openings in mild-climate and semi-exterior applications.
Custom colours can be matched to recognised international colour systems for project orders.
Four standard colours04 finishes
- Textured Black
- Deep Autumn Brown
- Light Ink Grey
- Soft Ivory
Product family
Doors
Opening
Sliding
System
Non-thermal break
Applications
Residential / Large openings
Technical summary
Product configuration and performance
- Aluminium grade
- 6063-T5 aluminium profile
- Profile wall thickness
- Outer frame 1.6 mm · 68 panel 3.0 mm · 100 panel 2.0 mm
- Frame depth
- Two-track 126.5 mm · three-track 190.5 mm
- Surface finish
- Powder coating
- Glass configuration
- 5 mm + 18A + 5 mm
Product highlights
L6 Heavy-Duty Sliding Door / Application 101 / 03
Air permeability
4.5 m³/(m·h)
Wind pressure resistance
5.0 kPa
Sound insulation
30 dB
U-factor
0.88
Opening methods
Reference diagrams
Two-track sliding
Three-track sliding
Four-track sliding
Five-track sliding
